FS-C1100
FS-C1100
Regular price
$230.00 USD
Regular price
Sale price
$230.00 USD
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
|
Manufacturer
|
NST
|
|
|
Series
|
FS-C
|
|
|
Packaging
|
Box
|
|
|
Part Status
|
Active
|
|
|
Sensing Method
|
Reflective
|
|
|
Sensing Distance
|
3.937" (100mm)
|
|
|
Voltage - Supply
|
12V ~ 24V
|
|
|
Response Time
|
1.5ms/5ms/10ms Switchable
|
|
|
Output Configuration
|
PNP or NPN Open Collector
|
|
|
Light Source
|
Red Laser Diode (655nm)
|
|
|
Connection Method
|
Cable
|
|
|
Ingress Protection
|
IP67
|
|
|
Cable Length
|
78.74" (2m)
|
|
|
Adjustment Type
|
Teaching Method
|
|
|
Operating Temperature
|
-10°C ~ 45°C
|
|
|
Repeatability
|
70 μm
|
|
|
Linearity
|
± 0.1 %
|
|
|
Base Product Number
|
FS-C1100
|
Materials
Materials
Main Housing: Cast AluminumFront Shield: PMMA
Care Instructions
Care Instructions
For user manuals, please send an email to sales@forgesensor.com and we will get in touch with you promptly.
